EE70 electronic transformer for transducer

Model No: EE70
Place of Origin: Guangdong,China (Mainland)
Phase: Single
Coil Structure: Toroidal
Coil Number: Autotransformer
Usage: Electronic
Brand Name: HangTung
Type: Electronic current transformer
Band name: Hang Tung
Certificate: UL/SGS/ROHS
Model No: EE70
Bobbin: EE70
core: PC44 or as require
Usage: ELectronics
Phase: single
Delivery Time: 10-20 days
Coil Number: Autotransformer

inquire

skypebasketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price: 1.0~5.0 USDProduction Capacity:8000/day
Payment Term:T/TPacking:CASE
MOQ:500 PCSDelivery Date:10-15 days
Means of Transport:Land, Ocean, Air

 EE70 welder transformer
"Green" Product , Experienced Technical Staff , Price ,Product Features , Prompt Delivery


  1.  Applicable frequency range: 20 to 100kHz :

Operating frequency: higher than 200kHz
High magnetic flux and low loss magnetic materials
With low leakage inductance and high efficiency .


 2.Applications:

PCB circuits, computer, TV, monitor, scanner, duplicator, mobile adapters, printer and other equipments and instruments

UL insulation system for Class B (130), F (155), H (180)



Model

Pin

Dimension(mm)

A

B

C+/-0.5

D+/-0.5

E+/-0.5

F

EE-8.3

6

8

8

6

4

2.5

8.3

EE-10

8

11.5

10.2

8

4

2.5

10.2

EE-13

10

12

12.5

8.5

4

2.5

13

EE-16-1

6

14.8

13.3

9

4

3

16

EE-16-2

10

15.4

13

10.5

4

3.2

17.1

EEL-16

10

28.5

16

12.3

4

4.3

21.9

EE-19-1

8

17.6

16

10

4

5

19

EE-19-2

10

17.2

16.2

13

4

3.9

20

EEL-19

10

31.5

16

10.5

4

4

21.1

EEL-19-1

10

15.6

30

24.1

4

3.5

21

EE-25-1

6

20

18.2

12.5

4

6.3

25.2

EE-25-2

8

21.7

17.5

12.6

4

5

25.2

EE-25-3

10

22.2

25

15.4

4

5

26.1

EEL-25

8

35.3

17.5

12.5

4

5

25.2

EE-30

10

21

29.2

25.2

4

5

30

EE-40

14

27.6

30.5

25.8

4

5

40

EE-42/15-1

12

33.8

44

35.5

4

5

42

EE-42/15-2

16

41.3

48

37.5

4

5

42

EE-42/15-3

18

48.7

32

27.5

4

5

45.1

EE-42/20-1

12

45

39.8

32.5

4

5

42

EE-42/20-2

16

44.2

50

37.8

4

5

42.2

EE-42/20-3

18

44.1

37

27.3

4

5

45.3

EE-50

20

50

50

45.5

4

5

55

EE-65

16

55.2

51.8

40

4

5

65

EE-70

18

59.5

56.8

50

4

5

70



High frequency transformer(EE,EI,ETD,PQ,RM,EF,ETC)

Full product range (custom made):
1) Air core inductors
2) Ferrite rod inductors
3) Fixed or adjustable inductors
4) High, medium or low frequency inductors
5) Iron-cored chokes or inductors
6) Metallized inductors
7) Miniature and subminiature chokes or inductors
8) Multi-layer chip inductors
9) Planar inductors
10) Pot inductors
11) Power chokes or inductors
12) RF chokes or inductors
13) RM inductors
14) R-type transformers
15) SMD inductors (molded chip, surface mounted)
16) Toroidal inductors
17) Variable chokes or inductors
18) Variable permeability inductors
19) All kinds of filters
20) All kinds of transformers



Applications:
1.Switching mode power
2.LCD/LED televisions &monitor
3.Communication equipment
4.Medical equipment
5.Computer peripheral devices



High frequency transformer:
1.ISO9001..CE,RoHs,UL.
2.Output power: 0.2W-2.0KW.
3.Rated current:2A-1500A loads.


High frequency transformer Applications:


1. VCRS,Copy machine,Audio equipment,Game machines;
2. TV sets, Microcomputer equitpmen

3. Communications control equipment
4. Printers,Terminals .

5. high good magnetic shield form itself and slight interferece.



Electrical Characteristics:



1. Operating Temperature range:-20 to +45

2. Storage temperature: -40 to +70

3. Switching frequency:1KHz to 200KHz

4. Withstanding voltage:1500/3750Vac for 1 minute between primary&secondary

5. Insulation resistance:500Vdc 100MΩ min.between primar&secondary.



 Normal parameters:

  EE type transformer
Part No. Terminal
 Pins Dimension mm Type Electrical parameter
A B C Inductance Output power(W)
EE-8.3 6.0 8.0 8.0 8.3 V 100.0uH 0.2-3.0
EE-10 8.0 11.5 10.2 10.2 V 80.0uH 0.5-5.0
EE-13 10.0 12.0 12.5 13.0 V 120.0uH 0.5-8.0
EE-16-1 6.0 14.8 13.3 16.0 V 90.0uH 1.0-10.0
EEL-16 10.0 28.5 16.0 21.9 V 600.0uH 2.0-15.0
EE-19-1 8.0 17.6 16.0 19.0 V 800.0uH 3.0-30.0
EEL19 10.0 31.5 16.0 21.1 V 1200.0uH 3.0-30.0
EE-25-1 6.0 20.0 18.2 25.2 V 2000.0uH 3.0-45.0
EEL25 8.0 35.3 17.5 25.2 V 2800.0uH 3.0-45.0
EE-30 10.0 21.0 29.2 30.0 H 900.0uH 3.0-50.0
EE-40 14.0 27.6 30.5 40.0 H 1500.0uH 3.0-55.0
EE-42/15-1 12.0 33.8 44.0 42.0 H 2000.0uH 3.0-80.0
EE-42/20-1 12.0 45.0 39.8 42.0 V 1900.0uH 3.0-90.0
EE-55 20.0 50.0 50.0 55.0 H 3000.0uH 3.0-150.0
EE-65 16.0 55.2 51.8 65.0 H 4500.0uH 3.0-300.0




 Pls send the following information via e-mail for quote:



1.Specification inclouding bobbin,core dimensions and winding drawing,

2.The quantity.


Package:


Our product:


EE65:

We can supply kinds of transformers, The products are widely used in a large variety of industries, computer, switch power, home appliances,LED,Plasma color television, instrumentation, green lighting, instrument and apparatus, the automobile electronics, and military industry. The product can be made of various specs,wecan supply the ferrite core to match the trasformers.


All products of the size,electrical performance can be designed according to customer requirements in R&D.


If you have a project or looking for electronic parts and components please contact with us!


Don't hesitate to contact us if any interested in our products.

Hang Tung Co. LTD Tel: 86-769-86638188
